FE-0365 | Showa | Flow Meter FE-0365 | Showa FE-0365 | Showa Vietnam
FE-0365 | Showa | Fl
Uni-D VietNam | Greentech Vietnam
.
| ype | general | FM-0350 | FE-0360 | FT-0370 |
| Small flow | FM-0355 | FE-0365 | FT-0375 | |
| function | Instant moment indication | Instant instant instruct & instruction · With 1 or 2 contacts (Reed switch contact) | Instant moment indication & 4-20mA, 2-wire | |
| appearance |
|
|
| |
| Case structure | ※ 2 Dustproof / drip-proof structure (equivalent to IP65) | |||
| Intrinsically safe explosion | ― | Certified with a dedicated zener barrier and set | ||
We also offer small flow type (eliminate PVC) respectively.
| Type | general | FM-0350 | FE-0360 | FT-0370 |
| Small flow | FM-0355 | FE-0365 | FT-0375 | |
| function | Instant moment indication | Instant instant instruct & instruction · With 1 or 2 contacts (Reed switch contact) | Instant moment indication & 4-20mA, 2-wire | |
| appearance |
|
|
| |
| Case structure | ※ 2 Dustproof / drip-proof structure (equivalent to IP65) | |||
| Intrinsically safe explosion | ― | Certified with a dedicated zener barrier and set | ||
specification
| General use | Small flow | Made from PVC | ||||
|---|---|---|---|---|---|---|
| appearance |
|
|
| |||
| Instruction only | FM-0350 | FM-0355 | FM-0350 | |||
| With contact | FE-0360 | FE-0365 | FE-0360 | |||
| 4-20mA | FT-0370 | FT-0375 | FT-0370 | |||
| Representative working fluid | Shimizu, industrial water, treated water, sludge water, OIL, air, nitrogen, steam, caustic soda | Shimizu, industrial water, treated water, OIL, air, nitrogen, caustic soda | Acid water, sea water, corrosive gas | |||
| accuracy | ±3％F.S. | |||||
| Connection standard | JIS 10K-FF option 5k, 20K, JPI, others | Rc 1/2 or JIS 10 K - FF option 5 k, 20 K, JPI, others | JIS10K-FF | |||
| Working pressure | 1.0 MPa or less Option 2 MPa | 1.4 MPa or less Option 2 MPa | 0.3MPa or less | |||
| Operating temperature | FM, FE is 120 ℃ or less (Option: Up to 200 ℃ for high temperature) FT, TC is 65 ℃ or less (Please consult us if it exceeds 65 ℃) | Below 40 ° C | ||||
| Wetted material | 1) SS 400 2) SUS 304 option SUS 316 | SUS304 option SUS316 | PVC | |||
| Flow direction | Downward → Up, Left → Right, Right → Left, Up → Down (Please consult us when flowing liquid at top → bottom) | |||||
| Caliber and flow rate | Water "m3/h" | ※ 1 air "m³ / h (ntp)" at 50 kPa at 20 ° C. | Water "l/h" | ※ 1 air "m³ / h (ntp)" at 50 kPa at 20 ° C. | Water "m3/h" | ※ 1 air "m³ / h (ntp)" at 50 kPa at 20 ° C. |
| 15A | 1.5-3 | 50-100 | 400-1200 | 12-36 | - | - |
| 20A | 1.5-3 | 50-100 | 400-1200 | 12-36 | - | - |
| 25A | 3-6 | 100-200 | 400-1200 | 12-36 | 2-5 | 70-150 |
| 32A | 3.6-8 | 120-260 | - | - | - | - |
| 40A | 3.6-12 | 120-390 | - | - | 3-12 | 100-390 |
| 50 A | 4-18 | 140-590 | - | - | 3.6-15 | 120-490 |
| 65 A | 10-36 | 350-1100 | - | - | 10-36 | 350-1000 |
| 80 A | 10-50 | 350-1600 | - | - | 10-40 | 350-1200 |
| 100A | 12-100 | 400-3200 | - | - | 15-100 | 500-1200 |
| 125A | 20-150 | 700-4900 | - | - | 20-120 | 700-4000 |
| 150A | 36-200 | 1200-6500 | - | - | 36-150 | 1200-4900 |
| 200A | 60-460 | 1700-15000 | - | - | - | - |
| 250A | 80-500 | 2700-16000 | - | - | - | - |
| 300A | 100-600 | 3300-19000 | - | - | - | - |
The maximum scale can be selected with a good numerical value from the above flow rate range. (Please refer to the "Scale section" table below.)
* 1 Air flow rate is at m / h (ntp) display scale when using 20 ℃, 50 kPa.
"Normal" (ntp) displayed after the flow rate unit indicates the volumetric flow rate of 0 ° C · 1 atm.
In addition, (standard) flow rate of 20 ° C · 1 atm (stp) can be produced.
Scale division
| Maximum scale value | 10 | 12 | 15 | 20 | 25 | 30 | 36 | 40 | 46 | 50 | 60 | 70 | 80 | 90 |
| Minimum scale | 2 | 2.5 | 3 | 4 | 5 | 6 | 8 | 8 | 10 | 10 | 12 | 15 | 15 | 20 |
| Width of 1 scale | 0.5 | 0.5 | 1 | 1 | 1 | 2 | 2 | 2 | 2 | 2 | 2 | 5 | 5 | 5 |
